RC-280

Two Shot Injection Molding Machine RC

射座型式
- K
- H
- G

This combination does not exist.

Add to Quote

Download

Specifications

Metric

Imperial

Add to Compare

Items

Unit

RC-280 (K)

RC-280 (H)

RC-280 (G)

Injection Unit

Screw diameter

mm inch

28 - 32 - 36 1.1 - 1.25 - 1.41

32 - 36 - 40 1.25 - 1.41 - 1.57

40 - 46 - 52 1.57 - 1.81 - 2.04

Screw ratio(L/D)

22.9 - 20 - 17.8

22.5 - 20 - 18

23 - 20 - 17.7

Calculated injection capacity

cm³ in³

86.2 - 113 - 143 5.26 - 6.89 - 8.72

129 - 163 - 201 7.87 - 9.94 - 12.26

251 - 332 - 425 15.31 - 20.25 - 25.93

Screw stroke

mm inch

140 5.51

160 6.29

200 7.87

Total heating wattage

KW HP

5.85 7.84

6.83 9.15

8.07 10.81

Clamping Unit

Clamping force

ton U.S ton

280 308.64

Nozzle center height

mm inch

500 19.68

Clamp stroke

mm inch

580 22.83

Tie-bar distance (H×V)

mm inch

920 x 510 36.22 x 20.07

Rotary table diameter

mm inch

980 38.58

Mold thickness (Min-Max.)

mm inch

120 - 550 4.72 - 21.65

Ejector stroke

mm inch

150 5.90

General

Servo motor (Standard)

KW HP

11+11 14+14

Machine weight

ton U.S ton

17 18.73

Machine dimensions

mm inch

5872 x 2338 x 2377 231.18 x 92.04 x 93.58

Add to quote

Specifications

Filter
Clamping force(ton)		280
Tie-bar distance (H×V)(mm)		920 x 510

Injection Unit
Screw diameter	mm inch	28 - 32 - 36 1.1 - 1.25 - 1.41
Screw ratio(L/D)		22.9 - 20 - 17.8
Calculated injection capacity	cm³ in³	86.2 - 113 - 143 5.26 - 6.89 - 8.72
Screw stroke	mm inch	140 5.51
Total heating wattage	KW HP	5.85 7.84

Clamping Unit
Clamping force	ton U.S ton	280 308.64
Nozzle center height	mm inch	500 19.68
Clamp stroke	mm inch	580 22.83
Tie-bar distance (H×V)	mm inch	920 x 510 36.22 x 20.07
Rotary table diameter	mm inch	980 38.58
Mold thickness (Min-Max.)	mm inch	120 - 550 4.72 - 21.65
Ejector stroke	mm inch	150 5.90
