VαⅢ-100
All-Electric Injection Molding Machine VαⅢ
Specifications
Add to
Compare
Items
Unit
Injection Unit
Calculated injection capacity
cm³
in³
62 - 80
3.78 - 4.88
117 - 148
7.13 - 9.03
Screw diameter
mm
inch
28 - 32
1.1 - 1.25
32 - 36
1.25 - 1.41
Screw stroke
mm
inch
100
3.93
145
5.70
Actual shot weight-PS
g
oz
58 - 76
2.0 - 2.7
110 - 139
3.9 - 4.9
Clamping Unit
Clamping force
ton
U.S ton
100
110.23
100
110.23
Clamp stroke
mm
inch
360
14.17
360
14.17
Platen dimension
mm
inch
640 × 595
25.19 x 23.42
640 × 595
25.19 x 23.42
Open daylight-Max.
mm
inch
810
31.88
810
31.88
Mold thickness (Min-Max.)
mm
inch
150 - 450
5.9 - 17.71
150 - 450
5.9 - 17.71
Tie-bar distance
mm
inch
460 × 410
18.11 x 16.14
460 × 410
18.11 x 16.14
Ejector stroke
mm
inch
100
3.93
100
3.93
General
Machine weight
ton
U.S ton
4.7
5.18
4.7
5.18
Machine dimensions
mm
inch
4559 x 1376 x 2083
179.48 x 54.17 x 82
4559 x 1376 x 2083
179.48 x 54.17 x 82
Add to quote
Specifications
| Filter | ||
|---|---|---|
| Clamping force(ton) | 100 | |
| Tie-bar distance (H×V)(mm) | 460 × 410 | |
| Shot weight(g) | oz | 58 - 76 2.0 - 2.7 |
| Injection Unit | ||
|---|---|---|
| Calculated injection capacity | cm³ in³ | 62 - 80 3.78 - 4.88 |
| Screw diameter | mm inch | 28 - 32 1.1 - 1.25 |
| Screw stroke | mm inch | 100 3.93 |
| Actual shot weight-PS | g oz | 58 - 76 2.0 - 2.7 |
| Clamping Unit | ||
|---|---|---|
| Clamping force | ton U.S ton | 100 110.23 |
| Clamp stroke | mm inch | 360 14.17 |
| Platen dimension | mm inch | 640 × 595 25.19 x 23.42 |
| Open daylight-Max. | mm inch | 810 31.88 |
| Mold thickness (Min-Max.) | mm inch | 150 - 450 5.9 - 17.71 |
| Tie-bar distance | mm inch | 460 × 410 18.11 x 16.14 |
| Ejector stroke | mm inch | 100 3.93 |
| General | ||
|---|---|---|
| Machine weight | ton U.S ton | 4.7 5.18 |
| Machine dimensions | mm inch | 4559 x 1376 x 2083 179.48 x 54.17 x 82 |
| Uncategorized | ||
|---|---|---|
| 射出單元 | F | |
