VαⅢ-250

All-Electric Injection Molding Machine VαⅢ

射出單元
- H
- J

This combination does not exist.

Add to Quote

Download

Specifications

Metric

Imperial

Add to Compare

Items

Unit

VαⅢ-250 (H)

VαⅢ-250 (J)

Injection Unit

Calculated injection capacity

cm³ in³

332 - 393 - 475 20.25 - 23.98 - 28.98

442 - 535 - 701 26.97 - 32.64 - 42.77

Screw diameter

mm inch

46 - 50 - 55 1.81 - 1.96 - 2.16

50 - 55 - 63 1.96 - 2.16 - 2.48

Screw stroke

mm inch

200 7.87

240 9.44

Actual shot weight-PS

g oz

312 - 369 - 447 11.0 - 13.0 - 15.7

415 - 502 - 659 14.6 - 17.7 - 23.2

Clamping Unit

Clamping force

ton U.S ton

250 275.57

Clamp stroke

mm inch

520 20.47

Platen dimension

mm inch

885 × 830 34.84 x 32.67

Open daylight-Max.

mm inch

1120 44.09

Mold thickness (Min-Max.)

mm inch

250 - 600 9.84 - 23.62

Tie-bar distance

mm inch

610 × 560 24.01 x 22.04

Ejector stroke

mm inch

150 5.90

General

Machine weight

ton U.S ton

11.5 12.67

Machine dimensions

mm inch

6588 x 1633 x 2461 259.37 x 64.29 x 96.88

Add to quote

Specifications

Filter
Clamping force(ton)		250
Tie-bar distance (H×V)(mm)		610 × 560
Shot weight(g)	oz	312 - 369 - 447 11.0 - 13.0 - 15.7

Injection Unit
Calculated injection capacity	cm³ in³	332 - 393 - 475 20.25 - 23.98 - 28.98
Screw diameter	mm inch	46 - 50 - 55 1.81 - 1.96 - 2.16
Screw stroke	mm inch	200 7.87
Actual shot weight-PS	g oz	312 - 369 - 447 11.0 - 13.0 - 15.7

Clamping Unit
Clamping force	ton U.S ton	250 275.57
Clamp stroke	mm inch	520 20.47
Platen dimension	mm inch	885 × 830 34.84 x 32.67
Open daylight-Max.	mm inch	1120 44.09
Mold thickness (Min-Max.)	mm inch	250 - 600 9.84 - 23.62
Tie-bar distance	mm inch	610 × 560 24.01 x 22.04
Ejector stroke	mm inch	150 5.90
