VαⅢ-350

All-Electric Injection Molding Machine VαⅢ

射出單元
- J
- K

This combination does not exist.

Add to Quote

Download

Specifications

Metric

Imperial

Add to Compare

Items

Unit

VαⅢ-350 (J)

VαⅢ-350 (K)

Injection Unit

Calculated injection capacity

cm³ in³

442 - 535 - 701 26.97 - 32.64 - 42.77

594 - 707 - 908 36.24 - 43.14 - 55.4

Screw diameter

mm inch

50 - 55 - 63 1.96 - 2.16 - 2.48

55 - 60 - 68 2.16 - 2.36 - 2.67

Screw stroke

mm inch

240 9.44

250 9.84

Actual shot weight-PS

g oz

415 - 502 - 659 14.6 - 17.7 - 23.2

557 - 663 - 851 19.6 - 23.3 - 30.0

Clamping Unit

Clamping force

ton U.S ton

350 385.80

Clamp stroke

mm inch

700 27.55

Platen dimension

mm inch

1090 x 1140 42.91 x 44.88

Open daylight-Max.

mm inch

1400 55.11

Mold thickness (Min-Max.)

mm inch

300 - 700 11.81 - 27.55

Tie-bar distance

mm inch

810 x 760 31.88 x 29.92

Ejector stroke

mm inch

180 7.08

General

Machine weight

ton U.S ton

17 (12+5)

Machine dimensions

mm inch

7.65 x 1.94 x 2.55 0.3 x 0.07 x 0.1

Add to quote

Specifications

Filter
Clamping force(ton)		350
Tie-bar distance (H×V)(mm)		810 × 760
Shot weight(g)	oz	415 - 502 - 659 14.6 - 17.7 - 23.2

Injection Unit
Calculated injection capacity	cm³ in³	442 - 535 - 701 26.97 - 32.64 - 42.77
Screw diameter	mm inch	50 - 55 - 63 1.96 - 2.16 - 2.48
Screw stroke	mm inch	240 9.44
Actual shot weight-PS	g oz	415 - 502 - 659 14.6 - 17.7 - 23.2

Clamping Unit
Clamping force	ton U.S ton	350 385.80
Clamp stroke	mm inch	700 27.55
Platen dimension	mm inch	1090 x 1140 42.91 x 44.88
Open daylight-Max.	mm inch	1400 55.11
Mold thickness (Min-Max.)	mm inch	300 - 700 11.81 - 27.55
Tie-bar distance	mm inch	810 x 760 31.88 x 29.92
Ejector stroke	mm inch	180 7.08
