Ve-120
Hydraulic Clamping Injection Molding Machine VE
Specifications
Add to
Compare
Items
Unit
Injection Unit
Calculated injection capacity
cm³
in³
145 - 181 - 222
8.84 - 11.04 - 13.54
Actual shot weight-PS
g
oz
136 - 170 - 208
4.8 - 6.0 - 7.3
Actual plasticizing capacity- PS
kg/hr
40 - 55 - 72
Injection pressure-Max.
kgf/cm2
Psi
1798 - 1440 - 1179
25572 - 20481 - 16768
Screw diameter
mm
inch
34 - 38 - 42
1.33 - 1.49 - 1.65
Screw L/D ratio
22 - 20 - 19
Screw stroke
mm
inch
160
6.29
Nozzle stroke
mm
inch
280
11.02
Clamping Unit
Clamping force
ton
U.S ton
140
154.32
Clamp stroke - Max.
mm
inch
350
13.77
Platen dimension
mm
inch
620 x 620
24.4 x 24.4
Tie-bar distance (H×V)
mm
inch
410 x 410
16.14 x 16.14
Open daylight-Max.
mm
inch
800
31.49
Mold thickness (Min-Max.)
mm
inch
120 - 450
4.72 - 17.71
Ejector stroke
mm
inch
100
3.93
General
Machine weight
ton
U.S ton
4.3
4.73
Machine dimensions
mm
inch
4600 x 1200 x 1800
181.1 x 47.24 x 70.86
Add to quote
Specifications
| Filter | ||
|---|---|---|
| Clamping force(ton) | 140 | |
| Tie-bar distance (H×V)(mm) | 410 × 410 | |
| Shot weight(g) | oz | 136 - 170 - 208 4.8 - 6.0 - 7.3 |
| Injection Unit | ||
|---|---|---|
| Calculated injection capacity | cm³ in³ | 145 - 181 - 222 8.84 - 11.04 - 13.54 |
| Actual shot weight-PS | g oz | 136 - 170 - 208 4.8 - 6.0 - 7.3 |
| Actual plasticizing capacity- PS | 40 - 55 - 72 | |
| Injection pressure-Max. | kgf/cm2 Psi | 1798 - 1440 - 1179 25572 - 20481 - 16768 |
| Screw diameter | mm inch | 34 - 38 - 42 1.33 - 1.49 - 1.65 |
| Screw L/D ratio | 22 - 20 - 19 | |
| Screw stroke | mm inch | 160 6.29 |
| Nozzle stroke | mm inch | 280 11.02 |
| Clamping Unit | ||
|---|---|---|
| Clamping force | ton U.S ton | 140 154.32 |
| Clamp stroke - Max. | mm inch | 350 13.77 |
| Platen dimension | mm inch | 620 x 620 24.4 x 24.4 |
| Tie-bar distance (H×V) | mm inch | 410 x 410 16.14 x 16.14 |
| Open daylight-Max. | mm inch | 800 31.49 |
| Mold thickness (Min-Max.) | mm inch | 120 - 450 4.72 - 17.71 |
| Ejector stroke | mm inch | 100 3.93 |
| General | ||
|---|---|---|
| Machine weight | ton U.S ton | 4.3 4.73 |
| Machine dimensions | mm inch | 4600 x 1200 x 1800 181.1 x 47.24 x 70.86 |
| Uncategorized | ||
|---|---|---|
| 射出單元 | － | |
