Ve / VsP / VR Series | Victor Taichung

Metric

Imperial

Clamping force(ton)
Tie-bar distance (H×V)(mm)
Shot weight(g) oz

rec.name — Ve Series

General-purpose models，90-280 ton

Ve / VsP / VR Series
Ve Series
Ve-90 Clamping force 110 ton Calculated injection capacity (Max) 181 cm³ Tie-bar distance (H×V) 360 x 360 mm	Ve-120 Clamping force 140 ton Calculated injection capacity (Max) 222 cm³ Tie-bar distance (H×V) 410 x 410 mm	Ve-140 Clamping force 140 ton Calculated injection capacity (Max) 326 cm³ Tie-bar distance (H×V) 410 x 410 mm	Ve-180A Clamping force 180 ton Calculated injection capacity (Max) 326 cm³ Tie-bar distance (H×V) 460 x 460 mm
Ve-180 Clamping force 180 ton Calculated injection capacity (Max) 517 cm³ Tie-bar distance (H×V) 460 x 460 mm	Ve-220 Clamping force 220 ton Calculated injection capacity (Max) 622 cm³ Tie-bar distance (H×V) 505 x 505 mm	Ve-280 Clamping force 280 ton Calculated injection capacity (Max) 1039 cm³ Tie-bar distance (H×V) 605 x 605 mm
VsP Series
VsP-60 射座型式 S K Clamping force 60 ton Calculated injection capacity (Max) 101.8 cm³ Tie-bar distance (H×V) 310 x 310 mm	VsP-90 射座型式 S K M Clamping force 90 ton Calculated injection capacity (Max) 182.2 cm³ Tie-bar distance (H×V) 360 x 360 mm	VsP-120 射座型式 K M Clamping force 120 ton Calculated injection capacity (Max) 182.6 cm³ Tie-bar distance (H×V) 410 x 410 mm	VsP-150 射座型式 M G Clamping force 150 ton Calculated injection capacity (Max) 265.9 cm³ Tie-bar distance (H×V) 460 x 460 mm
VsP-180 射座型式 G F Clamping force 180 ton Calculated injection capacity (Max) 475.2 cm³ Tie-bar distance (H×V) 510 x 510 mm	VsP-220 射座型式 G F Clamping force 220 ton Calculated injection capacity (Max) 475.2 cm³ Tie-bar distance (H×V) 560 x 560 mm	VsP-260 射座型式 F E Clamping force 260 ton Calculated injection capacity (Max) 871.6 cm³ Tie-bar distance (H×V) 615 x 615 mm
VR Series
VR-350 Injection Model F E N Clamping force 350 ton Calculated injection capacity (Max) 1433 cm³ Tie-bar distance (H×V) 700 x 700 mm	VR-450 Injection Model E N P Clamping force 450 ton Calculated injection capacity (Max) 2099 cm³ Tie-bar distance (H×V) 780 x 780 mm	VR-550 Injection Model N P R Clamping force 550 ton Calculated injection capacity (Max) 3142 cm³ Tie-bar distance (H×V) 850 x 850 mm	VR-700 Injection Model N P R Clamping force 700 ton Calculated injection capacity (Max) 3142 cm³ Tie-bar distance (H×V) 960 x 960 mm
VR-850 Injection Model P R S Clamping force 850 ton Calculated injection capacity (Max) 4467 cm³ Tie-bar distance (H×V) 1100 x 1000 mm	VR-1000 Injection Model R S J Clamping force 1000 ton Calculated injection capacity (Max) 6220 cm³ Tie-bar distance (H×V) 1250 x 1100 mm	VR-1300 Injection Model S J B Clamping force 1300 ton Calculated injection capacity (Max) 7964 cm³ Tie-bar distance (H×V) 1320 x 1280 mm
