VR-1000
High Speed Injection Molding Machine VR
Specifications
Add to
Compare
Items
Unit
Injection Model
Screw diameter
mm
inch
80 - 90 - 100
3.14 - 3.54 - 3.93
90 - 100 - 110
3.54 - 3.93 - 4.33
100 - 110 - 120
3.93 - 4.33 - 4.72
Calculated injection capacity
cm³
in³
2011 - 2545 - 3142
122.71 - 155.3 - 191.73
2990 - 3691 - 4467
182.46 - 225.23 - 272.59
4320 - 5227 - 6220
263.62 - 318.97 - 379.56
Actual shot weight-PS
g
oz
1885 - 2385 - 2945
66.4 - 84.0 - 103.7
2803 - 3460 - 4187
98.7 - 121.8 - 147.4
4049 - 4899 - 5830
142.6 - 172.5 - 205.3
Plastizing capacity
kg/hr
346 - 473 - 649
341 - 468 - 597
333 - 426 - 586
Screw L/D ratio
22 - 20 - 18
22 - 20 - 18
22 - 20 - 18
Screw stroke
mm
inch
400
15.74
470
18.50
550
21.65
Clamping Unit
Clamping force
ton
U.S ton
1000
1102.31
1000
1102.31
1000
1102.31
Clamp stroke - Max.
mm
inch
1200
47.24
1200
47.24
1200
47.24
Platen dimension
mm
inch
1820 x 1635
71.65 x 64.37
1820 x 1635
71.65 x 64.37
1820 x 1635
71.65 x 64.37
Tie-bar distance (H×V)
mm
inch
1250 x 1100
49.21 x 43.3
1250 x 1100
49.21 x 43.3
1250 x 1100
49.21 x 43.3
Open daylight-Max.
mm
inch
2400
94.48
2400
94.48
2400
94.48
Mold thickness (Min-Max.)
mm
inch
500 - 1200
19.68 - 47.24
500 - 1200
19.68 - 47.24
500 - 1200
19.68 - 47.24
Ejector stroke
mm
inch
300
11.81
300
11.81
300
11.81
General
Machine weight
ton
U.S ton
62.6
69.00
66.4
73.19
67.4
74.29
Machine dimensions
mm
inch
12890 x 3320 x 3150
507.48 x 130.7 x 124.01
12890 x 3320 x 3150
507.48 x 130.7 x 124.01
12890 x 3320 x 3150
507.48 x 130.7 x 124.01
Add to quote
Specifications
| Filter | ||
|---|---|---|
| Clamping force(ton) | 1000 | |
| Tie-bar distance (H×V)(mm) | 1250 × 1100 | |
| Shot weight(g) | oz | 1885 - 2385 - 2945 66.4 - 84.0 - 103.7 |
| Injection Model | ||
|---|---|---|
| Screw diameter | mm inch | 80 - 90 - 100 3.14 - 3.54 - 3.93 |
| Calculated injection capacity | cm³ in³ | 2011 - 2545 - 3142 122.71 - 155.3 - 191.73 |
| Actual shot weight-PS | g oz | 1885 - 2385 - 2945 66.4 - 84.0 - 103.7 |
| Plastizing capacity | 346 - 473 - 649 | |
| Screw L/D ratio | 22 - 20 - 18 | |
| Screw stroke | mm inch | 400 15.74 |
| Clamping Unit | ||
|---|---|---|
| Clamping force | ton U.S ton | 1000 1102.31 |
| Clamp stroke - Max. | mm inch | 1200 47.24 |
| Platen dimension | mm inch | 1820 x 1635 71.65 x 64.37 |
| Tie-bar distance (H×V) | mm inch | 1250 x 1100 49.21 x 43.3 |
| Open daylight-Max. | mm inch | 2400 94.48 |
| Mold thickness (Min-Max.) | mm inch | 500 - 1200 19.68 - 47.24 |
| Ejector stroke | mm inch | 300 11.81 |
| General | ||
|---|---|---|
| Machine weight | ton U.S ton | 62.6 69.00 |
| Machine dimensions | mm inch | 12890 x 3320 x 3150 507.48 x 130.7 x 124.01 |
| Uncategorized | ||
|---|---|---|
| Injection Model | J | |
