VR-1000

1000 (R)
https://www.victortaichung.com/web/image/product.template/122/image_1920?unique=338a2f6

High Speed Injection Molding Machine VR

  • Injection Model

This combination does not exist.

Specifications

Previous
Next
Add to Compare
Items
Unit
Injection Model
Calculated injection capacity
cm³ in³
2011 - 2545 - 3142 122.71 - 155.3 - 191.73
2990 - 3691 - 4467 182.46 - 225.23 - 272.59
4320 - 5227 - 6220 263.62 - 318.97 - 379.56
Actual shot weight-PS
g oz
1885 - 2385 - 2945 66.4 - 84.0 - 103.7
2803 - 3460 - 4187 98.7 - 121.8 - 147.4
4049 - 4899 - 5830 142.6 - 172.5 - 205.3
Plastizing capacity
kg/hr
346 - 473 - 649
341 - 468 - 597
333 - 426 - 586
Screw L/D ratio
22 - 20 - 18
22 - 20 - 18
22 - 20 - 18
Screw stroke
mm inch
400 15.74
470 18.50
550 21.65
Screw diameter
mm inch
80 - 90 - 100 3.14 - 3.54 - 3.93
90 - 100 - 110 3.54 - 3.93 - 4.33
100 - 110 - 120 3.93 - 4.33 - 4.72
Clamping Unit
Clamping force
ton U.S ton
1000 1102.31
1000 1102.31
1000 1102.31
Clamp stroke - Max.
mm inch
1200 47.24
1200 47.24
1200 47.24
Mold thickness (Min-Max.)
mm inch
500 - 1200 19.68 - 47.24
500 - 1200 19.68 - 47.24
500 - 1200 19.68 - 47.24
Platen dimension
mm inch
1820 x 1635 71.65 x 64.37
1820 x 1635 71.65 x 64.37
1820 x 1635 71.65 x 64.37
Tie-bar distance (H×V)
mm inch
1250 x 1100 49.21 x 43.3
1250 x 1100 49.21 x 43.3
1250 x 1100 49.21 x 43.3
Open daylight-Max.
mm inch
2400 94.48
2400 94.48
2400 94.48
Ejector stroke
mm inch
300 11.81
300 11.81
300 11.81
General
Machine weight
ton U.S ton
62.6 69.00
66.4 73.19
67.4 74.29
Machine dimensions
mm inch
12890 x 3320 x 3150 507.48 x 130.7 x 124.01
12890 x 3320 x 3150 507.48 x 130.7 x 124.01
12890 x 3320 x 3150 507.48 x 130.7 x 124.01
Uncategorized
Injection Model
R
S
J
Add to Inquiry
Add to Inquiry
Add to Inquiry
Add to Inquiry

Specifications

1000 (J)
Filter
Clamping force(ton) 1000
Tie-bar distance (H×V)(mm) 1250 × 1100
Shot weight(g) oz 66.4 - 84.0 - 103.7 1885 - 2385 - 2945
Injection Model
Calculated injection capacity cm³ in³ 122.71 - 155.3 - 191.73 2011 - 2545 - 3142
Actual shot weight-PS g oz 66.4 - 84.0 - 103.7 1885 - 2385 - 2945
Plastizing capacity 346 - 473 - 649
Screw L/D ratio 22 - 20 - 18
Screw stroke mm inch 15.74 400
Screw diameter mm inch 3.14 - 3.54 - 3.93 80 - 90 - 100
Clamping Unit
Clamping force ton U.S ton 1102.31 1000
Clamp stroke - Max. mm inch 47.24 1200
Mold thickness (Min-Max.) mm inch 19.68 - 47.24 500 - 1200
Platen dimension mm inch 71.65 x 64.37 1820 x 1635
Tie-bar distance (H×V) mm inch 49.21 x 43.3 1250 x 1100
Open daylight-Max. mm inch 94.48 2400
Ejector stroke mm inch 11.81 300
General
Machine weight ton U.S ton 69.00 62.6
Machine dimensions mm inch 507.48 x 130.7 x 124.01 12890 x 3320 x 3150
Uncategorized
Injection Model J
