VR-1300

1300 (S)
https://machine-tools.victortaichung.com/web/image/product.template/123/image_1920?unique=f8d0fc9

High Speed Injection Molding Machine VR

  • Injection Model

This combination does not exist.

Specifications

Previous
Next
Add to Compare
Items
Unit
Injection Model
Screw diameter
mm inch
90 - 100 - 110 3.54 - 3.93 - 4.33
100 - 110 - 120 3.93 - 4.33 - 4.72
110 - 120 - 130 4.33 - 4.72 - 5.11
Calculated injection capacity
cm³ in³
2990 - 3691 - 4467 182.46 - 225.23 - 272.59
4320 - 5227 - 6220 263.62 - 318.97 - 379.56
5702 - 6786 - 7964 347.95 - 414.1 - 485.99
Actual shot weight-PS
g oz
2803 - 3460 - 4187 98.7 - 121.8 - 147.4
4049 - 4899 - 5830 142.6 - 172.5 - 205.3
5344 - 6360 - 7465 188.2 - 224.0 - 262.8
Plastizing capacity
kg/hr
378 - 519 - 663
363 - 464 - 639
413 - 570 - 729
Screw L/D ratio
22 - 20 - 18
22 - 20 - 18
22 - 20 - 18
Screw stroke
mm inch
470 18.50
550 21.65
600 23.62
Clamping Unit
Clamping force
ton U.S ton
1300 1433.00
1300 1433.00
1300 1433.00
Clamp stroke - Max.
mm inch
1300 51.18
1300 51.18
1300 51.18
Platen dimension
mm inch
1990 x 1925 78.34 x 75.78
1990 x 1925 78.34 x 75.78
1990 x 1925 78.34 x 75.78
Tie-bar distance (H×V)
mm inch
1320 x 1280 51.96 x 50.39
1320 x 1280 51.96 x 50.39
1320 x 1280 51.96 x 50.39
Open daylight-Max.
mm inch
2600 102.36
2600 102.36
2600 102.36
Mold thickness (Min-Max.)
mm inch
550 - 1300 21.65 - 51.18
550 - 1300 21.65 - 51.18
550 - 1300 21.65 - 51.18
Ejector stroke
mm inch
330 12.99
330 12.99
330 12.99
General
Machine weight
ton U.S ton
79.2 87.30
80.2 88.40
81.8 90.16
Machine dimensions
mm inch
14550 x 3400 x 3400 572.83 x 133.85 x 133.85
14550 x 3400 x 3400 572.83 x 133.85 x 133.85
14550 x 3400 x 3400 572.83 x 133.85 x 133.85
Uncategorized
Injection Model
S
J
B
Add to Inquiry
Add to Inquiry
Add to Inquiry
Add to Inquiry

Specifications

1300 (B)
Filter
Clamping force(ton) 1300
Tie-bar distance (H×V)(mm) 1320 × 1280
Shot weight(g) oz 98.7 - 121.8 - 147.4 2803 - 3460 - 4187
Injection Model
Screw diameter mm inch 3.54 - 3.93 - 4.33 90 - 100 - 110
Calculated injection capacity cm³ in³ 182.46 - 225.23 - 272.59 2990 - 3691 - 4467
Actual shot weight-PS g oz 98.7 - 121.8 - 147.4 2803 - 3460 - 4187
Plastizing capacity 378 - 519 - 663
Screw L/D ratio 22 - 20 - 18
Screw stroke mm inch 18.50 470
Clamping Unit
Clamping force ton U.S ton 1433.00 1300
Clamp stroke - Max. mm inch 51.18 1300
Platen dimension mm inch 78.34 x 75.78 1990 x 1925
Tie-bar distance (H×V) mm inch 51.96 x 50.39 1320 x 1280
Open daylight-Max. mm inch 102.36 2600
Mold thickness (Min-Max.) mm inch 21.65 - 51.18 550 - 1300
Ejector stroke mm inch 12.99 330
General
Machine weight ton U.S ton 87.30 79.2
Machine dimensions mm inch 572.83 x 133.85 x 133.85 14550 x 3400 x 3400
Uncategorized
Injection Model B
