VR-350
High Speed Injection Molding Machine VR
Specifications
Add to
Compare
Items
Unit
Injection Model
Screw diameter
mm
inch
46 - 50 - 55
1.81 - 1.96 - 2.16
55 - 60 - 68
2.16 - 2.36 - 2.67
65 - 72 - 80
2.55 - 2.83 - 3.14
Calculated injection capacity
cm³
in³
332 - 393 - 475
20.25 - 23.98 - 28.98
570 - 679 - 872
34.78 - 41.43 - 53.21
946 - 1160 - 1433
57.72 - 70.78 - 87.44
Actual shot weight-PS
g
oz
312 - 368 - 445
11.0 - 13.0 - 15.7
534 - 636 - 817
18.8 - 22.4 - 28.8
886 - 1088 - 1343
31.2 - 38.3 - 47.3
Plastizing capacity
kg/hr
149 - 185 - 230
142 - 177 - 237
125 - 154 - 204
Screw L/D ratio
22 - 20 - 18
22 - 20 - 18
23 - 21 - 19
Screw stroke
mm
inch
200
7.87
240
9.44
285
11.22
Clamping Unit
Clamping force
ton
U.S ton
350
385.80
350
385.80
350
385.80
Clamp stroke - Max.
mm
inch
710
27.95
710
27.95
710
27.95
Platen dimension
mm
inch
1080 x 1080
42.51 x 42.51
1080 x 1080
42.51 x 42.51
1080 x 1080
42.51 x 42.51
Tie-bar distance (H×V)
mm
inch
700 x 700
27.55 x 27.55
700 x 700
27.55 x 27.55
700 x 700
27.55 x 27.55
Open daylight-Max.
mm
inch
1410
55.51
1410
55.51
1410
55.51
Mold thickness (Min-Max.)
mm
inch
250 - 700
9.84 - 27.55
250 - 700
9.84 - 27.55
250 - 700
9.84 - 27.55
Ejector stroke
mm
inch
160
6.29
160
6.29
160
6.29
General
Machine weight
ton
U.S ton
17
18.73
17
18.73
17
18.73
Machine dimensions
mm
inch
7835 x 1950 x 2440
308.46 x 76.77 x 96.06
7835 x 1950 x 2440
308.46 x 76.77 x 96.06
7835 x 1950 x 2440
308.46 x 76.77 x 96.06
Add to quote
Specifications
| Filter | ||
|---|---|---|
| Clamping force(ton) | 350 | |
| Tie-bar distance (H×V)(mm) | 700 × 700 | |
| Shot weight(g) | oz | 312 - 368 - 445 11.0 - 13.0 - 15.7 |
| Injection Model | ||
|---|---|---|
| Screw diameter | mm inch | 46 - 50 - 55 1.81 - 1.96 - 2.16 |
| Calculated injection capacity | cm³ in³ | 332 - 393 - 475 20.25 - 23.98 - 28.98 |
| Actual shot weight-PS | g oz | 312 - 368 - 445 11.0 - 13.0 - 15.7 |
| Plastizing capacity | 149 - 185 - 230 | |
| Screw L/D ratio | 22 - 20 - 18 | |
| Screw stroke | mm inch | 200 7.87 |
| Clamping Unit | ||
|---|---|---|
| Clamping force | ton U.S ton | 350 385.80 |
| Clamp stroke - Max. | mm inch | 710 27.95 |
| Platen dimension | mm inch | 1080 x 1080 42.51 x 42.51 |
| Tie-bar distance (H×V) | mm inch | 700 x 700 27.55 x 27.55 |
| Open daylight-Max. | mm inch | 1410 55.51 |
| Mold thickness (Min-Max.) | mm inch | 250 - 700 9.84 - 27.55 |
| Ejector stroke | mm inch | 160 6.29 |
| General | ||
|---|---|---|
| Machine weight | ton U.S ton | 17 18.73 |
| Machine dimensions | mm inch | 7835 x 1950 x 2440 308.46 x 76.77 x 96.06 |
| Uncategorized | ||
|---|---|---|
| Injection Model | N | |
