VR-550

550 (N)
https://www.victortaichung.com/web/image/product.template/119/image_1920?unique=5015f5c

High Speed Injection Molding Machine VR

  • Injection Model

This combination does not exist.

Specifications

Previous
Next
Add to Compare
Items
Unit
Injection Model
Calculated injection capacity
cm³ in³
946 - 1160 - 1433 57.72 - 70.78 - 87.44
1344 - 1659 - 2099 82.01 - 101.23 - 128.08
2011 - 2545 - 3142 122.71 - 155.3 - 191.73
Actual shot weight-PS
g oz
886 - 1088 - 1343 31.2 - 38.3 - 47.3
1259 - 1555 - 1968 44.3 - 54.7 - 69.3
1885 - 2385 - 2945 66.4 - 84.0 - 103.7
Plastizing capacity
kg/hr
188 - 231 - 305
210 - 277 - 379
247 - 338 - 464
Screw L/D ratio
23 - 21 - 19
22 - 20 - 18
23 - 21 - 19
Screw stroke
mm inch
285 11.22
330 12.99
400 15.74
Screw diameter
mm inch
65 - 72 - 80 2.55 - 2.83 - 3.14
72 - 80 - 90 2.83 - 3.14 - 3.54
80 - 90 - 100 3.14 - 3.54 - 3.93
Clamping Unit
Clamping force
ton U.S ton
550 606.27
550 606.27
550 606.27
Clamp stroke - Max.
mm inch
850 33.46
850 33.46
850 33.46
Mold thickness (Min-Max.)
mm inch
300 - 950 11.81 - 37.4
300 - 950 11.81 - 37.4
300 - 950 11.81 - 37.4
Platen dimension
mm inch
1260 x 1260 49.6 x 49.6
1260 x 1260 49.6 x 49.6
1260 x 1260 49.6 x 49.6
Tie-bar distance (H×V)
mm inch
850 x 850 33.46 x 33.46
850 x 850 33.46 x 33.46
850 x 850 33.46 x 33.46
Open daylight-Max.
mm inch
1800 70.86
1800 70.86
1800 70.86
Ejector stroke
mm inch
220 8.66
220 8.66
220 8.66
General
Machine weight
ton U.S ton
27.5 30.31
27.5 30.31
27.5 30.31
Machine dimensions
mm inch
9650 x 2150 x 2596 379.92 x 84.64 x 102.2
9650 x 2150 x 2596 379.92 x 84.64 x 102.2
9650 x 2150 x 2596 379.92 x 84.64 x 102.2
Uncategorized
Injection Model
N
P
R
Add to Inquiry
Add to Inquiry
Add to Inquiry
Add to Inquiry

Specifications

550 (R)
Filter
Clamping force(ton) 550
Tie-bar distance (H×V)(mm) 850 × 850
Shot weight(g) oz 31.2 - 38.3 - 47.3 886 - 1088 - 1343
Injection Model
Calculated injection capacity cm³ in³ 57.72 - 70.78 - 87.44 946 - 1160 - 1433
Actual shot weight-PS g oz 31.2 - 38.3 - 47.3 886 - 1088 - 1343
Plastizing capacity 188 - 231 - 305
Screw L/D ratio 23 - 21 - 19
Screw stroke mm inch 11.22 285
Screw diameter mm inch 2.55 - 2.83 - 3.14 65 - 72 - 80
Clamping Unit
Clamping force ton U.S ton 606.27 550
Clamp stroke - Max. mm inch 33.46 850
Mold thickness (Min-Max.) mm inch 11.81 - 37.4 300 - 950
Platen dimension mm inch 49.6 x 49.6 1260 x 1260
Tie-bar distance (H×V) mm inch 33.46 x 33.46 850 x 850
Open daylight-Max. mm inch 70.86 1800
Ejector stroke mm inch 8.66 220
General
Machine weight ton U.S ton 30.31 27.5
Machine dimensions mm inch 379.92 x 84.64 x 102.2 9650 x 2150 x 2596
Uncategorized
Injection Model R
