VR-550
High Speed Injection Molding Machine VR
Specifications
Add to
Compare
Items
Unit
Injection Model
Screw diameter
mm
inch
65 - 72 - 80
2.55 - 2.83 - 3.14
72 - 80 - 90
2.83 - 3.14 - 3.54
80 - 90 - 100
3.14 - 3.54 - 3.93
Calculated injection capacity
cm³
in³
946 - 1160 - 1433
57.72 - 70.78 - 87.44
1344 - 1659 - 2099
82.01 - 101.23 - 128.08
2011 - 2545 - 3142
122.71 - 155.3 - 191.73
Actual shot weight-PS
g
oz
886 - 1088 - 1343
31.2 - 38.3 - 47.3
1259 - 1555 - 1968
44.3 - 54.7 - 69.3
1885 - 2385 - 2945
66.4 - 84.0 - 103.7
Plastizing capacity
kg/hr
188 - 231 - 305
210 - 277 - 379
247 - 338 - 464
Screw L/D ratio
23 - 21 - 19
22 - 20 - 18
23 - 21 - 19
Screw stroke
mm
inch
285
11.22
330
12.99
400
15.74
Clamping Unit
Clamping force
ton
U.S ton
550
606.27
550
606.27
550
606.27
Clamp stroke - Max.
mm
inch
850
33.46
850
33.46
850
33.46
Platen dimension
mm
inch
1260 x 1260
49.6 x 49.6
1260 x 1260
49.6 x 49.6
1260 x 1260
49.6 x 49.6
Tie-bar distance (H×V)
mm
inch
850 x 850
33.46 x 33.46
850 x 850
33.46 x 33.46
850 x 850
33.46 x 33.46
Open daylight-Max.
mm
inch
1800
70.86
1800
70.86
1800
70.86
Mold thickness (Min-Max.)
mm
inch
300 - 950
11.81 - 37.4
300 - 950
11.81 - 37.4
300 - 950
11.81 - 37.4
Ejector stroke
mm
inch
220
8.66
220
8.66
220
8.66
General
Machine weight
ton
U.S ton
27.5
30.31
27.5
30.31
27.5
30.31
Machine dimensions
mm
inch
9650 x 2150 x 2596
379.92 x 84.64 x 102.2
9650 x 2150 x 2596
379.92 x 84.64 x 102.2
9650 x 2150 x 2596
379.92 x 84.64 x 102.2
Add to quote
Specifications
| Filter | ||
|---|---|---|
| Clamping force(ton) | 550 | |
| Tie-bar distance (H×V)(mm) | 850 × 850 | |
| Shot weight(g) | oz | 886 - 1088 - 1343 31.2 - 38.3 - 47.3 |
| Injection Model | ||
|---|---|---|
| Screw diameter | mm inch | 65 - 72 - 80 2.55 - 2.83 - 3.14 |
| Calculated injection capacity | cm³ in³ | 946 - 1160 - 1433 57.72 - 70.78 - 87.44 |
| Actual shot weight-PS | g oz | 886 - 1088 - 1343 31.2 - 38.3 - 47.3 |
| Plastizing capacity | 188 - 231 - 305 | |
| Screw L/D ratio | 23 - 21 - 19 | |
| Screw stroke | mm inch | 285 11.22 |
| Clamping Unit | ||
|---|---|---|
| Clamping force | ton U.S ton | 550 606.27 |
| Clamp stroke - Max. | mm inch | 850 33.46 |
| Platen dimension | mm inch | 1260 x 1260 49.6 x 49.6 |
| Tie-bar distance (H×V) | mm inch | 850 x 850 33.46 x 33.46 |
| Open daylight-Max. | mm inch | 1800 70.86 |
| Mold thickness (Min-Max.) | mm inch | 300 - 950 11.81 - 37.4 |
| Ejector stroke | mm inch | 220 8.66 |
| General | ||
|---|---|---|
| Machine weight | ton U.S ton | 27.5 30.31 |
| Machine dimensions | mm inch | 9650 x 2150 x 2596 379.92 x 84.64 x 102.2 |
| Uncategorized | ||
|---|---|---|
| Injection Model | R | |
