VR-700
High Speed Injection Molding Machine VR
Specifications
Add to
Compare
Items
Unit
Injection Model
Screw diameter
mm
inch
65 - 72 - 80
2.55 - 2.83 - 3.14
72 - 80 - 90
2.83 - 3.14 - 3.54
80 - 90 - 100
3.14 - 3.54 - 3.93
Calculated injection capacity
cm³
in³
946 - 1160 - 1433
57.72 - 70.78 - 87.44
1344 - 1659 - 2099
82.01 - 101.23 - 128.08
2011 - 2545 - 3142
122.71 - 155.3 - 191.73
Actual shot weight-PS
g
oz
886 - 1088 - 1343
31.2 - 38.3 - 47.3
1259 - 1555 - 1968
44.3 - 54.7 - 69.3
1885 - 2385 - 2945
66.4 - 84.0 - 103.7
Plastizing capacity
kg/hr
199 - 244 - 323
221 - 293 - 400
261 - 357 - 490
Screw L/D ratio
23 - 21 - 19
22 - 20 - 18
23 - 21 - 19
Screw stroke
mm
inch
285
11.22
330
12.99
400
15.74
Clamping Unit
Clamping force
ton
U.S ton
700
771.61
700
771.61
700
771.61
Clamp stroke - Max.
mm
inch
930
36.61
930
36.61
930
36.61
Platen dimension
mm
inch
1460 x 1460
57.48 x 57.48
1460 x 1460
57.48 x 57.48
1460 x 1460
57.48 x 57.48
Tie-bar distance (H×V)
mm
inch
960 x 960
37.79 x 37.79
960 x 960
37.79 x 37.79
960 x 960
37.79 x 37.79
Open daylight-Max.
mm
inch
1930
75.98
1930
75.98
1930
75.98
Mold thickness (Min-Max.)
mm
inch
400 - 1000
15.74 - 39.37
400 - 1000
15.74 - 39.37
400 - 1000
15.74 - 39.37
Ejector stroke
mm
inch
260
10.23
260
10.23
260
10.23
General
Machine weight
ton
U.S ton
32.5
35.82
33.3
36.70
33.9
37.36
Machine dimensions
mm
inch
9936 x 2290 x 2600
391.18 x 90.15 x 102.36
9936 x 2290 x 2600
391.18 x 90.15 x 102.36
9936 x 2290 x 2600
391.18 x 90.15 x 102.36
Add to quote
Specifications
| Filter | ||
|---|---|---|
| Clamping force(ton) | 700 | |
| Tie-bar distance (H×V)(mm) | 960 × 960 | |
| Shot weight(g) | oz | 886 - 1088 - 1343 31.2 - 38.3 - 47.3 |
| Injection Model | ||
|---|---|---|
| Screw diameter | mm inch | 65 - 72 - 80 2.55 - 2.83 - 3.14 |
| Calculated injection capacity | cm³ in³ | 946 - 1160 - 1433 57.72 - 70.78 - 87.44 |
| Actual shot weight-PS | g oz | 886 - 1088 - 1343 31.2 - 38.3 - 47.3 |
| Plastizing capacity | 199 - 244 - 323 | |
| Screw L/D ratio | 23 - 21 - 19 | |
| Screw stroke | mm inch | 285 11.22 |
| Clamping Unit | ||
|---|---|---|
| Clamping force | ton U.S ton | 700 771.61 |
| Clamp stroke - Max. | mm inch | 930 36.61 |
| Platen dimension | mm inch | 1460 x 1460 57.48 x 57.48 |
| Tie-bar distance (H×V) | mm inch | 960 x 960 37.79 x 37.79 |
| Open daylight-Max. | mm inch | 1930 75.98 |
| Mold thickness (Min-Max.) | mm inch | 400 - 1000 15.74 - 39.37 |
| Ejector stroke | mm inch | 260 10.23 |
| General | ||
|---|---|---|
| Machine weight | ton U.S ton | 32.5 35.82 |
| Machine dimensions | mm inch | 9936 x 2290 x 2600 391.18 x 90.15 x 102.36 |
| Uncategorized | ||
|---|---|---|
| Injection Model | R | |
