VR-700

700 (N)
https://www.victortaichung.com/web/image/product.template/120/image_1920?unique=90c0f07

High Speed Injection Molding Machine VR

  • Injection Model

This combination does not exist.

Specifications

Previous
Next
Add to Compare
Items
Unit
Injection Model
Calculated injection capacity
cm³ in³
946 - 1160 - 1433 57.72 - 70.78 - 87.44
1344 - 1659 - 2099 82.01 - 101.23 - 128.08
2011 - 2545 - 3142 122.71 - 155.3 - 191.73
Actual shot weight-PS
g oz
886 - 1088 - 1343 31.2 - 38.3 - 47.3
1259 - 1555 - 1968 44.3 - 54.7 - 69.3
1885 - 2385 - 2945 66.4 - 84.0 - 103.7
Plastizing capacity
kg/hr
199 - 244 - 323
221 - 293 - 400
261 - 357 - 490
Screw L/D ratio
23 - 21 - 19
22 - 20 - 18
23 - 21 - 19
Screw stroke
mm inch
285 11.22
330 12.99
400 15.74
Screw diameter
mm inch
65 - 72 - 80 2.55 - 2.83 - 3.14
72 - 80 - 90 2.83 - 3.14 - 3.54
80 - 90 - 100 3.14 - 3.54 - 3.93
Clamping Unit
Clamping force
ton U.S ton
700 771.61
700 771.61
700 771.61
Clamp stroke - Max.
mm inch
930 36.61
930 36.61
930 36.61
Mold thickness (Min-Max.)
mm inch
400 - 1000 15.74 - 39.37
400 - 1000 15.74 - 39.37
400 - 1000 15.74 - 39.37
Platen dimension
mm inch
1460 x 1460 57.48 x 57.48
1460 x 1460 57.48 x 57.48
1460 x 1460 57.48 x 57.48
Tie-bar distance (H×V)
mm inch
960 x 960 37.79 x 37.79
960 x 960 37.79 x 37.79
960 x 960 37.79 x 37.79
Open daylight-Max.
mm inch
1930 75.98
1930 75.98
1930 75.98
Ejector stroke
mm inch
260 10.23
260 10.23
260 10.23
General
Machine weight
ton U.S ton
32.5 35.82
33.3 36.70
33.9 37.36
Machine dimensions
mm inch
9936 x 2290 x 2600 391.18 x 90.15 x 102.36
9936 x 2290 x 2600 391.18 x 90.15 x 102.36
9936 x 2290 x 2600 391.18 x 90.15 x 102.36
Uncategorized
Injection Model
N
P
R
Add to Inquiry
Add to Inquiry
Add to Inquiry
Add to Inquiry

Specifications

700 (R)
Filter
Clamping force(ton) 700
Tie-bar distance (H×V)(mm) 960 × 960
Shot weight(g) oz 31.2 - 38.3 - 47.3 886 - 1088 - 1343
Injection Model
Calculated injection capacity cm³ in³ 57.72 - 70.78 - 87.44 946 - 1160 - 1433
Actual shot weight-PS g oz 31.2 - 38.3 - 47.3 886 - 1088 - 1343
Plastizing capacity 199 - 244 - 323
Screw L/D ratio 23 - 21 - 19
Screw stroke mm inch 11.22 285
Screw diameter mm inch 2.55 - 2.83 - 3.14 65 - 72 - 80
Clamping Unit
Clamping force ton U.S ton 771.61 700
Clamp stroke - Max. mm inch 36.61 930
Mold thickness (Min-Max.) mm inch 15.74 - 39.37 400 - 1000
Platen dimension mm inch 57.48 x 57.48 1460 x 1460
Tie-bar distance (H×V) mm inch 37.79 x 37.79 960 x 960
Open daylight-Max. mm inch 75.98 1930
Ejector stroke mm inch 10.23 260
General
Machine weight ton U.S ton 35.82 32.5
Machine dimensions mm inch 391.18 x 90.15 x 102.36 9936 x 2290 x 2600
Uncategorized
Injection Model R
