VsP-260
260 (F)
Hybrid Injection Molding Machine VsP
Specifications
Add to
Compare
Items
Unit
Injection Unit
Screw diameter
mm
inch
46 - 50 - 55
1.81 - 1.96 - 2.16
55 - 60 - 68
2.16 - 2.36 - 2.67
Calculated injection capacity
cm³
in³
332.4 - 392.7 - 475.2
20.28 - 23.96 - 28.99
570.2 - 678.6 - 871.6
34.79 - 41.41 - 53.18
Actual shot weight-PS
g
oz
312 - 368 - 445
11.0 - 13.0 - 15.7
534 - 636 - 817
18.8 - 22.4 - 28.8
Calculated plasticizing
kg/hr
122 - 151 - 188
114 - 142 - 190
Screw L/D ratio
mm
inch
21.7 - 20.0 - 18.2
0.85 - 0.78 - 0.71
21.8 - 20 - 17.6
0.85 - 0.78 - 0.69
Screw stroke
mm
inch
200
7.87
240
9.44
Clamping Unit
Clamping force
ton
U.S ton
260
286.60
260
286.60
Clamp stroke - Max.
mm
inch
580
22.83
580
22.83
Mold thickness (Min-Max.)
mm
inch
250 - 650
9.84 - 25.59
250 - 650
9.84 - 25.59
Platen dimension
mm
inch
890 x 885
35.03 x 34.84
890 x 885
35.03 x 34.84
Tie-bar distance (H×V)
mm
inch
615 x 615
24.21 x 24.21
615 x 615
24.21 x 24.21
Open daylight-Max.
mm
inch
1230
48.42
1230
48.42
Ejector stroke
mm
inch
170
6.69
170
6.69
General
Machine weight
ton
U.S ton
9.3
10.25
9.3
10.25
Machine dimensions (ES System option)
mm
inch
6330 x 1582 x 2388
249.21 x 62.28 x 94.01
6330 x 1582 x 2388
249.21 x 62.28 x 94.01
Uncategorized
射座型式
F
E
Add to Inquiry
Specifications
260 (E)
| Filter | ||
|---|---|---|
| Clamping force(ton) | 260 | |
| Tie-bar distance (H×V)(mm) | 615 x 615 | |
| Shot weight(g) | oz | 11.0 - 13.0 - 15.7 312 - 368 - 445 |
| Injection Unit | ||
|---|---|---|
| Screw diameter | mm inch | 1.81 - 1.96 - 2.16 46 - 50 - 55 |
| Calculated injection capacity | cm³ in³ | 20.28 - 23.96 - 28.99 332.4 - 392.7 - 475.2 |
| Actual shot weight-PS | g oz | 11.0 - 13.0 - 15.7 312 - 368 - 445 |
| Calculated plasticizing | 122 - 151 - 188 | |
| Screw L/D ratio | mm inch | 0.85 - 0.78 - 0.71 21.7 - 20.0 - 18.2 |
| Screw stroke | mm inch | 7.87 200 |
| Clamping Unit | ||
|---|---|---|
| Clamping force | ton U.S ton | 286.60 260 |
| Clamp stroke - Max. | mm inch | 22.83 580 |
| Mold thickness (Min-Max.) | mm inch | 9.84 - 25.59 250 - 650 |
| Platen dimension | mm inch | 35.03 x 34.84 890 x 885 |
| Tie-bar distance (H×V) | mm inch | 24.21 x 24.21 615 x 615 |
| Open daylight-Max. | mm inch | 48.42 1230 |
| Ejector stroke | mm inch | 6.69 170 |
| General | ||
|---|---|---|
| Machine weight | ton U.S ton | 10.25 9.3 |
| Machine dimensions (ES System option) | mm inch | 249.21 x 62.28 x 94.01 6330 x 1582 x 2388 |
| Uncategorized | ||
|---|---|---|
| 射座型式 | E | |
